| Code: | PMX-80D |  |
| Name: | Audio mixer |
 |
● 8 mono input channels with gold plated XLRs and balanced Line inputs ● 7-band graphic equalizer ● 2-band EQ for each channel ● Digital of the effector system inside ● Record and headphone monitor output ● Dual bands 10 digits LED level display ● REV for each channel ● Built-in audio power amplifier ● 2-track inputs assignable to master Mix output
Features:
Specifications:
| Model | PMX-80D |
| Channel MIC/line | 8CH |
| THD | ≤0.01% |
| Frequency Response | 20Hz-20kHz±3dB |
| S/N Ratio | ≥96dB |
| Max Output | 4V Max |
| Input Sensitivity | Mic-60dB |
| Line-40dB | |
| Tape-40dB | |
| Parametric EQ | Hi±15dB/12kHz |
| Low±15dB/80Hz | |
| Effector | Echo |
| Output Power | 2*200W 8Ω |
| Power Supply | AC 220V 50Hz |
