| Code: | EM-8U |  |
| Name: | Professional mixer EM series |
 |
Features:
| ● 6/8/12/16 channels |
| ● 48V phantom power |
| ● Dual 7-band graphic equalizer |
| ● 3-band EQ for each channel |
| ● 16 DSP effector and digital display |
| ● Record and headphone monitor output |
| ● Dual bands 10 digits LED level display |
| ● PAN,PFL and FX for each channel |
| ● ±20dB signal fluctuation switch |
| ● Built-in audio power amplifier |
| ● 1 Aux send and 1 internal AUX return for each channel |
| ● USB player |
Specifications:
| Model | EM-6U | EM-8U | EM-12U | EM-16U |
| Channel MIC/line | 6CH | 8CH | 12CH | 16CH |
| THD | ≤0.05% | ≤0.05% | ≤0.05% | ≤0.05% |
| Frequency Response | 20Hz-20kHz±3dB | 20Hz-20kHz±3dB | 20Hz-20kHz±3dB | 20Hz-20kHz±3dB |
| S/N Ratio | ≥97dB | ≥97dB | ≥97dB | ≥97dB |
| Max Output | 4V Max | 4V Max | 4V Max | 4V Max |
| Input Sensitivity | Mic-60dB | Mic-60dB | Mic-60dB | Mic-60dB |
| Line-40dB | Line-40dB | Line-40dB | Line-40dB | |
| Aux-40dB Tape-40dB | Aux-40dB Tape-40dB | Aux-40dB Tape-40dB | Aux-40dB Tape-40dB | |
| Parametric EQ | Hi±15dB/12kHz | Hi±15dB/12kHz | Hi±15dB/12kHz | Hi±15dB/12kHz |
| Mid±15dB/2.5kHz | Mid±15dB/2.5kHz | Mid±15dB/2.5kHz | Mid±15dB/2.5kHz | |
| Low±15dB/80Hz | Low±15dB/80Hz | Low±15dB/80Hz | Low±15dB/80Hz | |
| Phantom Power | +48V | +48V | +48V | +48V |
| Effector | Echo | Echo | Echo | Echo |
| Power Supply | AC 220V 50Hz | AC 220V 50Hz | AC 220V 50Hz | AC 220V 50Hz |
