| Code: | LY-600 |  |
| Name: | Sound pickup for security, DC12V, black case Φ6*16mm |
 |
 FEATURES |
| 1.Special import preamplifier IC |
| 2.M11 dynamic levels to enlarge |
| 3.Very low noise distortion |
| 4.Regulator circuit |
| SPECIFICATIONS |
| 1.Area:10~50m² (adjustable) |
| 2.Audio transmission distance:100m |
| 3.Sensitivity:-55dB±3dB |
| 4.Impedance:600Ω |
| 5.Signal amplitude:0~6Vp-p |
| 6.Frequency range:100Hz~15KHz |
| 7.Power supply:DC6V~12V 20mA |
| 8.Wire length:95mm |
| 9.Dimension::Φ6*16mmmm |
