| Code: | LY-506 |  |
| Name: |
 |
 FEATURES |
| 1.Low-noise processing chips |
| 2.Special explosion-proof metal |
| 3.Power polarity protection circuit |
| SPECIFICATIONS |
| 1.Area:10~150m² (adjustable) |
| 2.Audio transmission distance:600m |
| 3.Sensitivity:-65dB±3dB |
| 4.Impedance:600Ω |
| 5.Signal amplitude:0~5Vp-p |
| 6.Frequency range:200Hz~10KHz |
| 7.Power supply:DC9V~12V 20mA |
| 8.Wire length:130mm |
| 9.Dimension:60*45*19mm |
