| Code: | CMA31-DC12V-C |  |
| Name: | CMA31-C 5pin DC12V 30A 14VDC |
 |
Specifications:
| MODEL: | CMA31-DC12V-C | |
| COIL DATA | ||
| Nominal Voltage | 12V DC | |
| Coil Restistance(Ω+/-10%) | 90 | |
| Operate Voltage(≤VDC) | 8.4 | |
| Release Voltage(≥VDC) | 1.2 | |
| Coil Power(Mw) | 1600 | |
| CONTACT DATA | ||
| Contact Form | C-1 form C | |
| Contact Material | Ag Alloy | |
| Contact Rating | 30A 14VDC Resistive (1 Form C) | |
| Max.Switching Voltage | 75VDC | |
| Max.Switching Current | 40A | |
| Max.Switching Power | 420W | |
| Max.Load Current(14VDC Load Voltage) | NO | NC |
| Contact Rating Current | 40A | 30A |
| Max.Make Current | 100A | 30A |
| Max.Break Current | 40A | 30A |
| Contact Resistance | ≤100m (6VDC 1A) | |
| Life | ||
| Electrical | 100,000 operations | |
| Mechanical | 10,000,000 operations | |
| GENERAL DATA | ||
| Insulation Resistance | Min.100M 500VDC | |
| Dielectric Strength | 500VAC,1min between open contacts | |
| 500VAC,1min between coil and contacts | ||
| Operate Time | Max.10ms | |
| Release Time | Max.10ms | |
| Operate Temperature | -40 ~ +85 C | |
| Shock Resistance | ||
| Endurance | 1,000m/s2 | |
| Misoperation | 100m/s2 | |
| Vibration Resistance | ||
| Endurance | 10 -55Hz ,double amplitude 1.5mm | |
| Misoperation | 10 -55Hz ,double amplitude 1.5mm | |
| Weight | Approximately 36.0g | |
