| Code: | Fast Recovery Rectifier |  |
| Name: |
 |
| Item No. |
Max peak Rectified voltage |
Max Average Rectified Current |
6Max Forward Peak Surge Current |
Max reverse Current |
Max Forward Current |
Max Forward Voltage |
Max Recovery Time |
| V pk=V | Io=A | I fm=A | Ir=uA | I fm=UA | V fm=V | T=us | |
| FR101 | 50 | 1 | 30 | 5 | 1 | 1.3 | 150 |
| FR102 | 100 | 1 | 30 | 5 | 1 | 1.3 | 150 |
| FR103 | 200 | 1 | 30 | 5 | 1 | 1.3 | 150 |
| FR104 | 400 | 1 | 30 | 5 | 1 | 1.3 | 150 |
| FR105 | 600 | 1 | 30 | 5 | 1 | 1.3 | 250 |
| FR106 | 800 | 1 | 30 | 5 | 1 | 1.3 | 500 |
| FR107 | 1000 | 1 | 30 | 5 | 1 | 1.3 | 500 |
| FR151 | 50 | 1.5 | 60 | 5 | 1.5 | 1.3 | 150 |
| FR152 | 100 | 1.5 | 60 | 5 | 1.5 | 1.3 | 150 |
| FR153 | 200 | 1.5 | 60 | 5 | 1.5 | 1.3 | 150 |
| FR154 | 400 | 1.5 | 60 | 5 | 1.5 | 1.3 | 150 |
| FR155 | 600 | 1.5 | 60 | 5 | 1.5 | 1.3 | 250 |
| FR156 | 800 | 1.5 | 60 | 5 | 1.5 | 1.3 | 500 |
| FR157 | 1000 | 1.5 | 60 | 5 | 1.5 | 1.3 | 500 |
| FR201 | 50 | 2 | 70 | 5 | 2 | 1.3 | 150 |
| FR202 | 100 | 2 | 70 | 5 | 2 | 1.3 | 150 |
| FR203 | 200 | 2 | 70 | 5 | 2 | 1.3 | 150 |
| FR204 | 100 | 2 | 70 | 5 | 2 | 1.3 | 150 |
| FR205 | 600 | 2 | 70 | 5 | 2 | 1.3 | 250 |
| FR206 | 800 | 2 | 70 | 5 | 2 | 1.3 | 500 |
| FR207 | 1000 | 2 | 70 | 5 | 2 | 1.3 | 500 |
| BY296 | 100 | 2 | 70 | 5 | 2 | 1.3 | 500 |
| BY297 | 200 | 2 | 70 | 5 | 2 | 1.3 | 500 |
| BY298 | 400 | 2 | 70 | 5 | 2 | 1.3 | 500 |
| BY299 | 800 | 2 | 70 | 5 | 2 | 1.3 | 500 |
| FR251 | 50 | 2.5 | 150 | 5 | 2.5 | 1.3 | 150 |
| FR252 | 100 | 2.5 | 150 | 5 | 2.5 | 1.3 | 150 |
| FR253 | 200 | 2.5 | 150 | 5 | 2.5 | 1.3 | 150 |
| FR254 | 400 | 2.5 | 150 | 5 | 2.5 | 1.3 | 150 |
| FR255 | 600 | 2.5 | 150 | 5 | 2.5 | 1.3 | 250 |
| FR256 | 800 | 2.5 | 150 | 5 | 2.5 | 1.3 | 500 |
| FR257 | 1000 | 2.5 | 150 | 5 | 2.5 | 1.3 | 500 |
| FR301 | 50 | 3 | 200 | 10 | 3 | 1.3 | 150 |
| FR302 | 100 | 3 | 200 | 10 | 3 | 1.3 | 150 |
| FR303 | 200 | 3 | 200 | 10 | 3 | 1.3 | 150 |
| FR304 | 400 | 3 | 200 | 10 | 3 | 1.3 | 150 |
| FR305 | 600 | 3 | 200 | 10 | 3 | 1.3 | 250 |
| FR306 | 800 | 3 | 200 | 10 | 3 | 1.3 | 500 |
| FR307 | 1000 | 3 | 200 | 10 | 3 | 1.3 | 500 |
| BY396 | 100 | 3 | 150 | 10 | 3 | 1.3 | 500 |
| BY397 | 200 | 3 | 150 | 10 | 3 | 1.3 | 500 |
| BY398 | 400 | 3 | 150 | 10 | 3 | 1.3 | 500 |
| BY399 | 800 | 3 | 150 | 10 | 3 | 1.3 | 500 |
| FR601 | 50 | 6 | 300 | 10 | 6 | 1.3 | 150 |
| FR602 | 100 | 6 | 300 | 10 | 6 | 1.3 | 150 |
| FR603 | 200 | 6 | 300 | 10 | 6 | 1.3 | 150 |
| FR604 | 400 | 6 | 300 | 10 | 6 | 1.3 | 150 |
| FR605 | 600 | 6 | 300 | 10 | 6 | 1.3 | 250 |
| FR606 | 800 | 6 | 300 | 10 | 6 | 1.3 | 500 |
| FR607 | 1000 | 6 | 300 | 10 | 6 | 1.3 | 500 |
